Roof Detail DWG Detail for AutoCAD

Roof Detail DWG Detail for AutoCAD

DETAIL TEXAS ROOF WITH CHANEL AND PERIMETER TRUSSES OF POLISHING CONCRETE ON SCREEN STUCANET

Drawing labels, details, and other text information extracted from the CAD file (Translated from Galician):

detail, holders of bar strollers, dripper running from esp., frame of angles of c.a.c., corner angle of expansion bolts of c.a.c., Galv steel river channel. caliber, smooth bars of c.a.c., stucanet mesh sneaker, close, wall of bloq’s receives plain, roof beam with con. rest, double gauge steel beam, esp plate section of con with anchored leg plate filled with conico hole, galv steel carriages calibre po pazko c.a.c., Imperial type clay tile roof on galvanized zinc lamellae caliper side, Smooth carriage aligners with spaced washer nut, corner angle of, imperial clay stopper, varies

Raw text data extracted from CAD file:

\A1;.50 \A1;.20 \A1;.18 \A1;VARIA 5 5 DETALLE ESCALA:1:10 ES-37 2 SOSTENEDORES DE CARRIOLAS DE BARRAS DE 3/8"d GOTERO CORRIDO DE >1"X1"X 1/8" DE ESP. ENTRAMADO DE ANGULOS DE 1"X1"X3/16" @ .60 C.A.C. ANGULO CORRIDO DE 1 1/2"X1 1/2" CON PERNOS DE EXPANSION DE 3/8"d X 2 1/2" @ .60 C.A.C. CANAL FLUVIAL DE ACERO GALV. CALIBRE # 18 BARRAS LISAS DE 3/8"d @ .25 C.A.C. MALLA STUCANET + REPELLO LISO CERCHA PARED DE BLOQ'S 8" + REP. LISO A/C VIGA DE TECHO VT-1 DE .20 X .30 CON 2 # 5 CORRIDOS, EST. # 3: 9 @ .075 RESTO @ .15 VIGA DE ACERO DOBLE CARRIOLA 6" X 2", CALIBRE 16 PLATO DE ACERO, 1/4" DE ESP. X SECCION DE COLUMNA, CON 4 # 4 CON PATA ANCLADA A PLATO RELLENANDO AGUJERO CONICO CARRIOLAS DE 6" X 2" DE ACERO GALV. CALIBRE #16 TI- PO PAZKO @ .60 C.A.C. TECHO DE TEJAS DE ARCILLA TIPO IMPERIAL SOBRE LAMINAS DE ZINC GALVANIZADO ONDU- LADO CALIBRE #26. ALINEADORES DE CARRIOLAS DE 1/2"d LISAS CON TUERCA Y ARANDELA ESPACIADAS @ L/2 ANGULO CORRIDO DE 1 1/2"X1 1/2"X 3/16" TAPON DE ARCILLA TIPO IMPERIAL A ES-37 5 VARIA \A1; 2" E6013 1/8" 2" E6013 1/4"

Language	N/A
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete, Steel
Measurement Units
Footprint Area
Building Features	A/C
Tags	autocad, barn, chanel, concrete, cover, dach, DETAIL, DWG, hangar, lagerschuppen, perimeter, roof, roof detail, screen, shed, structure, terrasse, texas, toit, trusses
