This comprehensive drawing package depicts a multi-story residential house design (5M) featuring floor plans and elevation views. This layout includes multiple two-story townhouse units with a common floor plan configuration. Each unit features a distinctive stairwell placement, multiple bedrooms, and standardized door/window placements (utilizing blocks D1-D3 and W1-W2). The first floor appears to contain common living areas with the upper floor dedicated to bedrooms. Interior walls are clearly delineated with appropriate thickness for load-bearing vs. partition walls. The elevation views showcase a clean, contemporary façade with regular window placement and minimal ornamentation. The floor-to-ceiling height appears to be standard residential (approximately 8′-6″). The design maximizes spatial efficiency while maintaining separation between public and private zones; however, the relatively narrow footprint may create challenges for furniture placement in some rooms. The repeating unit design suggests this may be part of a multi-unit development or row house configuration.
5M House Multi-Level Residential Floor Plan with Elevations
