This drawing depicts a decorative CNC panel with an intricate swirl pattern designed for fabrication on a 4′ × 8′ sheet. This pattern features a continuous series of interlocking spiral and curl elements creating negative space cut-outs suitable for screens, dividers, or decorative wall panels. The design maintains consistent toolpath widths throughout, optimized for CNC routing with standard bits (likely 1/4″ or 3/8″). The arrangement balances negative and positive space to maintain structural integrity while achieving an ornate appearance. The repetitive spiral motif creates visual interest while the uniform pattern distribution ensures consistent material strength across the panel. The drawing includes precise dimensional callouts (4′-0″ × 8′-0″) and is configured for direct CNC machining with appropriate polyline entities. Note that material thickness is not specified but would typically be 1/2″ to 3/4″ for this application, with consideration needed for adequate support during the cutting process.
CNC Router Swirl Pattern Panel for 4’x8′ Decorative Screen
