Command Center Architectural Plans with Elevations and Sections

Project Overview

This comprehensive architectural drawing set depicts a two-story command center facility for Vale Manganês S.A. in Ouro Preto, MG, Brazil. This structure has a footprint of 111.37m² and incorporates multiple specialized spaces across ground and first floors.

Key Architectural Features:
– Two-story reinforced building with command/control rooms, meeting spaces, and support areas
– Elevator shaft with equipment room and foundation details (extending to -1.90m)
– Designated safety passages with galvanized sheet metal roofing on 70×70mm metal columns
– Staircases with 28cm treads and 18cm risers, featuring 110cm height handrails
– Specialized ventilation systems including basculant windows (80×40cm)

Floor Configuration

– Ground Floor: Primary command room (48.99m²), meeting rooms, server room (CPD), circulation spaces, and accessible facilities
– First Floor: Staff rest areas (40.13m²), kitchen (20.16m²), and sanitary facilities including PNE-accessible bathrooms

The project incorporates structural steel elements with detailed and thorough connections shown for the passageway roof system. Finish specifications include white and green painted walls throughout with granite countertops (Branco Siena) in specific areas. Mechanical systems include provisions for 12000 BTU air conditioning units with designated power connections at 130cm height.
