Full layout plan for a large logistics warehouse (Galpão A) at 1:500 scale. Includes specialized storage zones for brands like Black and Decker, Sephora, and Omron with specific racking requirements. Detailed elevations for various pallet racking modules (porta paletes) are included, showing beam heights reaching over 10m. Mezzanine floor layout covers administrative areas, meeting rooms, and director offices with furniture blocks. Restrooms are detailed with standard and accessible (PNE) layouts. The main warehouse area features a 12m clear height, dock zones, and inbound staging.Planta de layout completa do Galpão A incluindo áreas de estocagem, mezanino administrativo e detalhes técnicos de porta paletes.
Complete logistics warehouse layout with racking systems and offices
