First garage level (G1) floor plan for a large commercial complex with multiple angular wings. The drawing features several distinct zones highlighted in green that appear to be designated parking areas, with circulation paths between them. Multiple stairwells and elevator cores are strategically positioned at key junctions, providing vertical circulation between levels. The floor plan follows an irregular geometric footprint with angled walls that respond to site constraints. The drawing includes structural grid lines, dimensional references, and column placements throughout. Notable features include service areas, circulation zones marked with directional indicators, and utility spaces. The scale is indicated as 1:75 on the legend in the bottom right corner, along with a north arrow and plotting configuration information. The layout demonstrates a sophisticated approach to space planning with careful attention to traffic flow and structural integration.
G1 Level Floor Plan for Multi-Wing Commercial Structure
