Industrial Factory Facades and Elevations DWG

Two long architectural elevations of an industrial building complex with multiple chimneys and warehouses.

Facade elevations for a large industrial complex. I’ve included two long views with the chimneys and saw-tooth roofines in this DWG.

FREE

File Details

File Type
DWG
Type
Elevation
Language
Portuguese
Materials
Masonry, Steel, Concrete
Units
Metric
Area
Over 5000 m² (53819.5 ft²)
Features
Garage
Uploaded by
CAD Workshop
Category
Commercial, Industrial
Published
Jun 15, 2026

Download faster, ad-free, with more daily files from $7/mo

Tags

architectural elevation building elevations Cad Block DWG facade factory heritage building industrial architecture industrial facade sawtooth roof site plan warehouse elevation
