Iron Door DWG Detail for AutoCAD

Iron Door DWG Detail for AutoCAD

Metalic Door Details

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

metal, swing door detail, elevation, welded hinge, simple cathedral glass, welding, frame detail, all metal is treated with anticorrosive and, double hand of black paint., cathedral glass is simple, grid type.

Raw text data extracted from CAD file:

.85 1.05 2.00 METALICA DETALLE DE PUERTA BATIENTE ESCALA 1/20 ELEVACION Plancha de metal de 2mm Bisagra soldada Marco de metal 1" Vidrio catedral simple Tee 1" .85 5 5 ESCALA 1/5 1 - 1 2 1 2 1 ESCALA 1/5 2 - 2 Eje de 1" Marco 1" Vidrio catedral simple Tee 1" Vidrio catedral simple Tee 1" Eje de 1" Marco 1" Bisagra soldad de 3" Vidrio catedral simple Eje de 1" Marco 1" Tee 1" Tee 1" Tee 1" Eje de 1" Plancha de metal de 2mm ESCALA 1/5 ESCALA 1/2 Marco 1" Eje de 1" Tee 1" Soldadura Soldadura Detalle de Marco Marco 1" Eje de 1" Vidrio catedral simple Todo el metal es tratado con anticorrosivo y doble mano de pintura negra. El vidrio catedral es de tipo cuadriculado, simple.

Language	Spanish
Drawing Type	Detail
Category	Doors & Windows
Additional Screenshots
File Type	dwg
Materials	Glass, Other
Measurement Units	Metric
Footprint Area
Building Features
Tags	autocad, DETAIL, details, door, DWG, iron, metalic
