Harness details for the 178545 cable used in the Salobo autonomous drilling project. It’s a 24-meter run of CAT 5e with M12 D Coded connectors at both ends, incl. braided sleeving detail. We’ve got the full elevation view and front-end connector pinouts. All dims in metric—the cable is labeled as 24.0 m. Title block has the Flanders and Vale logos, plus standard plotting instructions for pen weights. It’s listed as “Sem Escala” since it’s a schematic/detail view.
M12 D Coded Connector Harness 178545 Detail
