This drawing set depicts a comprehensive security guard booth design with section, elevation, and plan views along with construction details. The structure features a pitched roof pavilion-style design approximately 5.36m wide with a concrete foundation and decorative railings. The section view reveals a ceiling height of 3.0m and includes specific mounting details for windows and fixtures. The booth incorporates specialized security features with dimensions clearly marked throughout – the interior space measures approximately 3.50m x 4.05m with window openings at 1.65m width. Construction details show precise material connections, including tiled surfaces (450x450mm) and concrete foundation specifications. The pavilion-style design balances functional security requirements with aesthetic considerations, featuring decorative elements while maintaining clear sightlines for surveillance purposes.
Security guard Booth Section, Elevation and Plan Details
