Symbology – Pipeline 2D DWG Block for AutoCAD
Library in 2D – Pipeline
Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):
elbow, Pipe connection, Eccentric reduction, Concentric reduction, Tee straight side, Welded collar flange, Vein straightener, Safety relief angle, ball valve, Compound valve, Pneumatic ball valve, check valve, Butterfly valve, Check valve check, Globe valve, Needle valve, Valve plug, same, Turbine meter, meter of, Roots meter, Orifice plate meter, Ultrasonic meter, filter, Filter separator, pressure gauge, Chacho trap, relief valve, Filter separator, elbow, same
Raw text data extracted from CAD file:
Language | Spanish |
Drawing Type | Block |
Category | Water Sewage & Electricity Infrastructure |
Additional Screenshots |
![]() |
File Type | dwg |
Materials | |
Measurement Units | |
Footprint Area | |
Building Features | |
Tags | autocad, block, digester, DWG, fuel, gas, griffin, kläranlage, library, pipeline, symbology, tank, treatment plant |
