A comprehensive 103.68kW rooftop-mounted solar photovoltaic installation for Building B in Hobeop-myeon. The system features 288 Hanwha 360W solar modules arranged in 16-series 18-parallel configuration with a 15° fixed tilt angle.
System Specifications:
– Module type: Hanwha 360Wp (1,960×1,000×46mm)
– Array configuration: 16 series × 18 parallel strings
– Total capacity: 103.68kW
– Mounting type: Roof-fixed structure
– Inverter configuration: Two 50kW grid-tied inverters (TRIO-50.0-TL-OUTD)
Structural Details: The mounting system utilizes structural square tubes (100×100×2.3T) for main supporting members, with L-50×50×5t angle bars for cross-bracing. Connection to existing roof purlins via 300×130×9mm base plates with M6 fasteners. The system includes detailed earthing connections (10Ω special Type 3 grounding).
