Acoustic Insulation Details DWG Detail for AutoCAD

Detail Wall – Floor

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Meeting wall flooring existing plaster wall. Uprights mm. Panel of rock wool. Density rocdan sandwich acoustic. Gypsum plasterboards m.a.d. Channel profile mm. Durable stand. Impact noise insulation. Impact of mortar layer reinforced with mesh. Finishing pavement. Shock absorber series

Raw text data extracted from CAD file:

ENCUENTRO PARED – SUELO 1. Pared existente enlucida. 2. Perfil montante 46 mm. 3. Panel de lana de roca. Densidad 70 kg/m 3 . ROCDAN 231/40 4. Sandwich acústico. 2 placas yeso laminar 13 + M.A.D. 4 5. Perfil canal 48 mm. 6. Soporte resistente. 7. Aislamiento a ruido de impacto. IMPACTODAN 10 8. Capa de mortero armado con mallazo. 9. Pavimento de terminación. 10. Amortiguador SERIE SNP-15.
