Aluminum Panels, Alucubone DWG Block for AutoCAD

Aluminum Panels, Alucubone DWG Block for AutoCAD

Detalles – especificaciones – dimensionamiento

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

compound acfoam decreasing, separation sheet, polystyrene insulation, gypsum board, galvanized wire, main channel, profile of, ceiling, connection plate, main beam ipc, connection plate, main beam ipc, cabbage. sec. composed:, two channel plates, alucobond sheet, lacquered thickness mm., structure of, crystal clear, central core of polyethylene, vertical channel, ipc beam connection plate, horizontal channel, angle of, ceramic tile, concrete template, natural terrain, line pedregal color puebla, Mca. staged vitromex, with mca pegazulejo. crest, layer thickness cm., losacero cal system., poor, tepetate stuffing, stainless steel, ceramic tile, jame stony line, Mca. staged vitromex, with mca pegazulejo. crest, see

Raw text data extracted from CAD file:

A Compuesto ACFoam Decreciente 8' Lamina de Separacion FR50 Aislamiento de Poliestireno Tablero de Yeso Alambre Galvanizado No.18 Canaleta Principal Perfil "C" de ¾" Plafon Placa de Conexion Viga Principal IPC 33"x16" Placa de Conexion Viga Principal IPC 33"x16" Col. Sec. Compuesta: Dos Canales Y Placas Corridas, 12"x12" Lamina de Alucobond Lacado Espesor 6 mm. Estructura de Cristal Claro de 6mm. Nucleo Central De Polietileno Canal "C" Vertical Placa de conexion a Viga IPC Canal "C" Horizontal. Angulo de 3/4" Loseta Ceramica de 33.3 x 33.3 ø#6@25Cm Plantilla de Concreto Terreno Natural Linea Pedregal Color Puebla (Beige) Mca. Vitromex asentada con pegazulejo Mca. Crest. Capa de Compresion, Espesor 6 cm. Sistema Losacero QL-99-M62 Cal. 24 Pobre f'c=100 Kg/cm Relleno de Tepetate Acero Inoxidable Loseta Ceramica de 33.3 x 33.3 Linea Pedregal Color Jame (Café) Mca. Vitromex asentada con pegazulejo Mca. Crest. NPT±0.00 NPT+5.10 N+9.20 Ver D1

Language	Spanish
Drawing Type	Block
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Aluminum, Concrete, Steel
