Bridge deck reinforcement details

Technical drawing of bridge deck reinforcement plans and longitudinal elevation with pier details.

Bridge deck reinforcement layout including top and bottom slab details. Shows longitudinal and transverse rebar (dia. 16, 20 and 25) @ 125mm c/c and pier head sections.

FREE

File Details

File Type
DWG
Type
Detail
Language
English
Materials
Steel, Concrete
Units
Metric
Area
Over 5000 m² (53819.5 ft²)
Uploaded by
Eng_Plans
Category
Public Facilities, Roads, Bridges and Dams
Published
Jul 13, 2026

Download faster, ad-free, with more daily files from $7/mo

Tags

bridge bridge deck civil engineering pier rebar reinforcement RFT slab structural
