Intake and sand trap design for Bendung Cimoyan. includes 1:200 site plan & sections A-A through K-K. concrete specs for K-225 and K-350 masonyr. site features trashrack, guard house, & stone masonry 1:4. river embankment protection uses gabions. levels marked for water elevations. part of a BBWS infrastructure project. Desain saluran intake dan kantong lumpur.
Cimoyan Weir Intake Design
