Constructive Joint Between Slabs – DWG Block for AutoCAD

Seismic structures

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

existing, Form factor sikaflex mm, Concrete structure, new, Abrasive cleaning, To waterproof with similar sika, Reinforcement does not cross, Nice metal, Sikarod, depth, width, When there is a joint between walls, Detail of joint between slabs, N.a., Wall, Concrete structure, Mezzanine floor, Sikaflex putty, Thick floor

Raw text data extracted from CAD file:

\A1;0.02 m \A1;0.15 m \A1;0.15 m \A1;0.05 \A1;0.05 EXISTENTE FACTOR DE FORMA SIKAFLEX 1A=ANCHO=20 mm ESTRUCTURA EN CONCRETO NUEVA LIMPIEZA CON DISCO ABRASIVO IMPERMEABILIZAR CON SIKA O SIMILAR REFUERZO NO ATRAVIESA O GRATA METALICA 0.0 0.0 SIKAROD Ø 1 1/8″ (29 mm.) PROFUNDIDAD = 1 ANCHO = 2 CUANDO EXISTA JUNTA ENTRE MUROS CUANDO EXISTA JUNTA ENTRE MUROS DETALLE DE JUNTA CONSTRUCTIVA ENTRE LOSAS DETALLE DE JUNTA CONSTRUCTIVA ENTRE LOSAS N.P.A MURO MURO ESTRUCTURA EN CONCRETO ENTREPISO Y/O CEBADÒ MASILLA SIKAFLEX 1A ESPESOR PISO 0.0 0.0 0.0
