DWG STEEL FRAME FULL COURT ESC 1 100 WALL DETAIL; Ceiling and floor

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

revoke deployed metal project, expanded polystyrene, phenolic multilaminate, pgc panel amount, anchor type strap panel foundation, mezzanine border pgc, upper edge of the pgc span, bottom edge of pgc, crystal, lower floor of pgc panel, substrate support beam, sealant on the gasket, female multilaminate substrate esp mm, strapping, pgc eaves edge border, upper pgc cord with lip-wing trim, union: self-drilling screws, pgc vertical pendulum, pgc bottom rope, pgc top rope, horizontal buckle of intermediate pgc, pgc central buckle bracing, diagonal pgc, pgc longitudinal belts, polystyrene film microns, welded metal mesh, poor concrete subfloor, corrugated zinc plate

Raw text data extracted from CAD file:

\A1;1.72 \A1;4.20 \A1;2.42 \A1;0.60 1.721914895339399 2.415579777364293 0.6000000000000014 5 Revoque proyecto sobre metal desplegado Poliestireno expandido de 20 kg/m3 Multilaminado fenolico + aislaciòn hidofuga Montante panel PGC 100x89 Anclaje tipo fleje del panel a la fundación Cenefa del entrepiso PGC 200 x 89 \W8.49013; Solera de 10, \W6.56592; borde Superior del vano \W6.56592; "U" \W7.47252; PGC 100X89 \W8.68943; Solera de 10, \W7.01830; borde inferior del vano \W7.01830; "U" \W7.47252; PGC 100X89 Cristal 3+3mm\fArial|b1|i0|c0|p34;\H1.1111x; Solera inferio del panel PGC 100 x 89 Viga de apoyo del substrato \W8.80232; Sellador \W8.80232; en la \W9.12467; junta (Acero/ HºAº) Substrato : Multilaminado femolino esp 25 mm Strapping: Fleje metalico c/1.50m\fArial|b1|i0|c0|p34;\H1.1111x; Cenefa de borde de alero PGC Cordon superior PGC 100 x89 con recorte de ala y labio Union: Tornillos Autoperforantes Pendolòn Vertical PGC Cordon inferior de cabriada PGC 100 x89 Cordon superior de cabriada PGC 100 x89 Arriostre horizontal de pendolón intermedio PGC Arriostre del pendolón Central PGC Diagonal PGC 100x89 \W9.31059; Diagonal PGC 100x89 \W9.31059; Diagonal PGC 100x89 Correas Longitudinales PGC 100x89 Film de Poliestileno 200 micrones Malla metalica electrosoldada Contrapiso de hormigon pobre 0.08m Chapa ondulada de Cinc
