Detailed structural design of an industrial crane rail system with 6-meter span support beams (BK6). The drawing includes various configurations of crane rail components:
Primary Components:
– Standard beam profiles (BK6, BK6-6, BK12) with structural reinforcements
– End beams with specialized support configurations (BK6k, BK6u)
– Column connection brackets (KK1, KK2) with various mounting arrangements
– Buffer stops designed for different load capacities (5-32 tons)
Technical Specifications:
– Standard beam spacing: 6000mm with 150-250mm column support zones
– Connection details include M16, M20, and M12 bolts with specific torque requirements
– Weld specifications (Kf1, Kfr) for different load capacities
– Support brackets for various column types with width considerations (>550mm)
– End beam reinforcement plates with thickness 16-25mm depending on load requirements
The drawing provides five recommended structural solutions for column connections, including options for end columns, middle columns, and installations where column height exceeds 12m. All designs comply with Russian structural standards with specific attention to impact resistance according to SP 20.13330.2016.
