Crossbows And Springs DWG Block for AutoCAD

Crossbows And Springs DWG Block for AutoCAD

Crossbows and springs is formed with a view and also some screws with their descriptions.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

cut, conventional, cylindrical compression spring in rectangular section profile, cylindrical compression spring in circular section profile, – without eyelets, – with eyelets, – without eyelets and with central clamp, – with eyelets and with central clamp, screw for wood, metal screw, sheet metal screw, metal screw with cylindrical head, inlay hexagon, cut, conventional, wire section spring with circular section, spring compression wire with circular sector

Raw text data extracted from CAD file:

REPRESENTACION DE TORNILLOS (NORMA IRAM 4520) \W8.83681; BALLESTAS \W8.20261; Real \W8.80577; Representación \W9.25949; Designación Corte Convencional Resorte cilindrico de compresion en perfil de seccion rectangular Resorte cilindrico de compresion en perfil de seccion circular Resorte cilindrico de compresion en perfil de seccion rectangular Resorte cilindrico de compresion en perfil de seccion rectangular \W7.84866; REAL \W6.95147; CONVENCIONAL \W9.98949; REPRESENTACION \W8.83681; BALLESTAS - Sin ojales - Con ojales - Sin ojales y con abrazadera central - Con ojales y con abrazadera central REPRESENTACION DE TORNILLOS (NORMA IRAM 4520) Tornillo para madera Tornillo para metales Tornillo para chapa Tornillo para metales con cabeza cilindrica hexagono embutido REPRESENTACION DE BALLESTAS METALICAS (NORMA IRAM 4525) \W7.21052; REPRESENTACION DE RESORTES Y BALLESTAS METALICAS \W9.98421; (NORMA IRAM 4535) \W5.83222; TORNILLOS \W6.83867; NOMBRES \W7.84866; REAL \W9.98949; REPRESENTACION \W9.22856; RESORTES CORTE CONVENCIONAL Resorte cilindrico de compresion en perfil de seccion rectangular Resorte cilindrico de compresion en perfil de seccion circular Resorte cilindrico de compresion en perfil de seccion rectangular Resorte de traccion de alambre de seccion circular Resorte de compresion de alambre de sector circular

Language	Spanish
Drawing Type	Block
Category	Industrial
Additional Screenshots
File Type	dwg
Materials	Wood, Other
Measurement Units	Metric
