Double Kitchen Sink DWG Block for AutoCAD

Installation of double kitchen sink

Drawing labels, details, and other text information extracted from the CAD file (Translated from Portuguese):

front view, scale:, finished floor, side view, finished floor, go box of, fat, sink, cold sewage pvc weldable with flexible metal drain thread for kitchen sink for sink kitchen pvc weldable with pvc thread for secondary sewage pvc short bronze hot water bolsaxbipp nipple bronze

Raw text data extracted from CAD file:

\A1;0.60 \A1;0.55 \A1;0.55 \A1;0.60 \A1;0.80 \A1;0.20 \A1;0.20 \A1;0.55 \A1;0.60 \A1;0.80 VISTA DE FRENTE ESCALA: 1:1 7 6 7 AF AQ 5 AQ AF PISO ACABADO VISTA LATERAL 7 PISO ACABADO 6 5 1 2 4 3 VAI A CAIXA DE GORDURA PIA \C4;LEGENDA \H0.04;\C3;ÁGUA FRIA E ESGOTO 1-JOELHO 90° PVC SOLDÁVEL E COM ROSCA METÁLICA d 20mmx1/2″ 2-LIGAÇÃO FLEXÍVEL 3-VÁLVULA DE ESCOAMENTO PARA PIA DE COZINHA 4-SIFÃO PARA PIA COZINHA d 1.1/2″x1.1/2″ 5-JOELHO 90° PVC SOLDÁVEL E COM ROSCA d 40mmx1.1/2″ 6-TUBO PVC PARA ESGOTO SECUNDÁRIO d 40mm 7-CURVA 90° PVC CURTA d 40mm ÁGUA QUENTE 1-COTOVELO DE BRONZE BOLSAxBOLSA d 22mmx1/2″E NIPLE DE BRONZE d 1/2″ 0.60 0.55 0.55 0.60 0.80 0.20 0.20 0.55 0.60 0.80
