Fiber Optic Network Infrastructure Plan for Residential Complex

Comprehensive telecommunications infrastructure layout for a residential development featuring villas and high-rise buildings. This plan details fiber optic cable routing, equipment specifications, and network topology for a mixed-use development. Key components include:

Network Distribution:
– Main telecommunications cabinets (9 total) with varying port configurations (8-244 ports)
– Primary backbone: dual HDPE D130/100 conduits (350m)
– Secondary backbone: single HDPE D130/100 conduits (160m)
– Branch conduits: HDPE D105/80 (1240m)
– Fiber optic cable specifications: 4-core, 8-core, 32-core, and 48-core single-mode
– Coaxial cable network (RG-6) for television distribution

Equipment Details:
– Optical fiber distribution frames (ODF) with port capacities from 8 to 244
– Optical/electrical converters for signal transmission
– Television signal amplifiers and splitters (2-port, 3-port, 6-port, 8-port configurations)
– Power requirements: 220V AC dual outlets (16A)

The system architecture facilitates internet connectivity, telephone services, and television distribution throughout the development with dedicated telecom manholes placed at 25-50m intervals for cable pulling and maintenance.
