Layout for a fire pump house (Casa de Bombas) from an industrial as-built project. Main pump is a Grundfos 8AE20G diesel unit rated for 2500 GPM @ 150 PSI. Also includes the Jockey pump for system pressure (1.2m3/h @ 160mca). Drawing shows the 570 m³ fire water reservoir connection, full suction/discharge manifold, and pipe sizes. Automation panel details and electrical layout included too. Materials are cabon steel Sch10/Sch20 for main lines and galvanized for small trim. Scaled at 1:30 with full legends for valves and fittings. Original text is in Portuguese.
Fire Pump House Layout
