Industrial Ship – Details

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

raised plant, scale:, dimensions in mms., flat number, tube type, thickness, weight, Basic square pyramidal module, minor side, relationship, distributed load, mesh type, spatial mesh, support in all perimeter knots, inside diameter, plant seen from above, raised, general outline, lower bars, top bars, diagonal bars, width by height, personal door of, wide for coat., holes for sectional doors, holes for sectional doors, wide for coat., structural type, support in spherical cap, beam, belt, deck deck, belt, support sheet, bituminous membrane, oxide layer, thermal isolation, vapor barrier, oxide layer, bituminous membrane, dimensions in mms., structure, scale:, For the vertical enclosures of the ship, panels of hidden fixings will be used, post, close ship detail, ship length:, work:, panel, interior ship, raised plant, dimensions in mms., flat number

Raw text data extracted from CAD file:

4000 4000 52000 52000 Planta y alzados ESCALA: 1 / 100 Cotas en mms. Nº PLANO 48000 2000 2000 TUBO TIPO P Espesor Peso (kp/m) H L MÓDULO BÁSICO PIRAMIDAL DE BASE CUADRADA Lado menor B Relación A/B Carga distribuida Tipo de malla 37,9 4000 C55 220 1 52000 MALLA ESPACIAL Apoyo en todos los nudos perimetrales 4000 Diámetro interior 8 200 5 5 PLANTA VISTA DESDE ARRIBA ALZADO ESQUEMA GENERAL Barras inferiores Barras superiores Barras diagonales 16 3 24 23 22 21 20 19 18 17 4 3 2 1 52000 1876,98 8000 52000 ANCHO POR 2.1m. DE ALTO PUERTA PERSONAL DE 1m. DE DE ANCHO POR 3m. DE ALTO,CON ABRIGO. HUECOS PARA PUERTAS SECCIONALES DE 2.75m. 52000 9320 1000 2 1 1 2 3 4 5 6 7 HUECOS PARA PUERTAS SECCIONALES DE 2.75m. DE ANCHO POR 3m. DE ALTO,CON ABRIGO. TIPO ESTRUCTURAL APOYO EN CASQUETE ESFÉRICO VIGA CORREA CUBIERTA DECK Correa Chapa soporte Membrana bituminosa Membrana bituminosa Capa de oxiasfalto Aislamiento termico Barrera de vapor Capa de oxiasfalto Capa de oxiasfalto Membrana bituminosa 15 14 13 12 11 10 9 8 7 6 5 Cotas en mms. ESTRUCTURA ESCALA: 1 / 300 1000 Para los cerramientos verticales de la nave se utilizará paneles de fijaciones ocultas "ACH" Poste +0.00 DETALLE CIERRE DE NAVE LONGITUD NAVE: 390 OBRA: 240 1000 Panel 52000 INTERIOR NAVE 52000 9320 1000 52000 9320 1000 9320 1000 52000 7 6 5 4 Planta y alzados Cotas en mms. Nº PLANO

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features	Deck / Patio
Tags	autocad, DETAIL, details, DWG, industrial, ship, stahlrahmen, stahlträger, steel, steel beam, steel frame, structure en acier
