This technical drawing details a mechanical connecting plate with a symmetrical arrangement of six bolt holes. This plate has overall dimensions of 100 mm in height and approximately 145 mm in width, with curved contours on both sides creating a distinctive profile. The central section features a rectangular area with dimensions of 40 mm in height, while the upper and lower sections curve outward, each with a height of 30 mm. Four mounting holes are positioned at the corners of the central rectangular section, with two additional holes centered at the top and bottom edges. All holes appear to be of similar diameter, designed for standard fasteners. The curved edges include a 6 mm radius detail, providing stress relief at potential concentration points. The symmetric design suggests this component serves as a junction plate, possibly for load transfer between mechanical assemblies.
Mechanical Connecting Plate Detail Drawing with Bolt Holes
