This technical drawing presents comprehensive details of medical gas systems for healthcare facilities, featuring oxygen supply manifolds and medical vacuum plant configurations. The drawing includes four elevation details showing both single cylinder (ESM) and multi-cylinder systems (MCS2) for medical oxygen and air supply. The oxygen manifold systems display 2×1 and 2×4 cylinder configurations with essential components including regulators with gauges, relief valves, isolation valves, and 22mm distribution lines. The medical vacuum plant section illustrates a duplex pump system (714 LPM at 450 mmHg) with bacterial filters, shut-off valves, and an air receiver tank. Equipment specifications indicate a total motor rating of 6 kW (2 pumps at 3 kW each), 380V/3-phase/60Hz power supply, and a receiver volume of 785 liters. The system dimensions are 2150mm×1300mm×1450mm with 500mm recommended service clearance. The drawing includes critical installation details such as steel angular cylinder holders (3mm×75mm×75mm), chain securing systems, non-return valves, and test points for system verification.
Medical Gas Systems Elevation Detail – Oxygen and Vacuum Equipment
