AC02 platform lift technical drawing with floor plans and full mechanical specs. Includes cabin sizes for 1100×1400 and 900×1400 models. The plan shows configurations for both adjacent and opposite entry doors. technical data: 325 kg capacity, trapezoidal screw drive (fuso com rosca trapezoidal), and a 2.5 m/min speed. Covers 2 stops with a max rise of 2.0m and a standard 70mm pit.Drawings are in mm, scale 1:1. I’ve included tower and cabin views as indicated in the layers. Desenho técnico da Plataforma AC02 com planta baixa e especificações.
Plataforma AC02 Accessibility Lift Technical Drawing
