Comprehensive Door Assembly Details
This technical detail sheet illustrates four distinct door types specifically designed for residential applications: kitchen timber door, pivot double timber door, pivot timber door, and toilet timber sliding door. Each assembly is presented with corresponding elevations, sections, plans, and construction details at scales of 1:20 and 1:5.
Door Specifications:
• Kitchen Timber Door: 996mm W × 2438mm H × 45mm thick with structural opening 1076mm × 2476mm. Features 2-hour fire rating to British Standard.
• Pivot Double Timber Door: 1410mm W × 2450mm H × 45mm thick with structural opening 1500mm × 2500mm. Includes timber veneer finish.
• Pivot Timber Door: 1096mm W × 2450mm H × 45mm thick with structural opening 1190mm × 2500mm. Incorporates 8mm thick glass panels and timber finish.
• Toilet Sliding Door: 950mm W × 2490mm H × 45mm thick with structural opening 900mm × 2500mm. Utilizes Hafele Junior 160/B sliding hardware (Cat. No. 941.60.002).
Construction details highlight key components: solid timber jambs and architraves, timber lipping, veneer finishes, hardwood formwork, floor spring plates, and hardware specifications. Ironmongery includes stainless steel lever handles with satin dull hairline finish from Hafele (Cat. No. 910.38.255). The drawing incorporates critical installation notes regarding fire rating certification and hardware specification adjustments based on non-standard door dimensions.
