Roofs DWG Block for AutoCAD

Roof on metallic joists without ceiling

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Upper forged, Light profile, Joists ipn ipe, Forged placner, Compression layer, Max. Cms., without, Solution placner, Cover over metal joists

Raw text data extracted from CAD file:

FORJADO SUPERIOR PERFIL LIGERO U – Z VIGUETAS IPN – IPE PLACNER FORJADOS CAPA DE COMPRESION ( 3 cms.) Max. 90 cms. Max. 90 cms. SIN CIELO-RASO SOLUCION PLACNER CM-1.- CUBIERTA SOBRE VIGUETAS METALICAS
