Shoe Construction Detail DWG Detail for AutoCAD

Shoe Construction Detail DWG Detail for AutoCAD

Detail of shoe construction steel

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

steel gutter, for cable tensioner guide, Tensioning cable, welded to the gusset, Holding dog, tensor, steel gusset, of minimum, thickness, gusset welding, column, column finish with, cut face cut, oriented to the center of the column, circular suction with diameter, of for tensioner hitch, minimum cut, of the, decorative draperies, from the center of the distance, from the top of, the column in the part is, trace the line is divided into, parts that will serve for, The upper suction measures, of diameter the lower suction the, the central suction leaves the tangents of, the other two suajes., Tensioning cable, steel column, with a diameter of, caliber to calculate., steel column, with a diameter of, caliber to calculate., stroke axis, double hex nut, squared shields, of steel, over the center., steel plate, rectangular side by side, that will be the base of the column, steel tube, with external diameter, caliber to be defined., double hexagonal nut., metal washer., stirrups, cement floor stencils, tamped brick pedacer, for leveling., isolated concrete shoe, armed with rods, on both sides, rods, Anchored to the shoe., steel plate, rectangular side by side, that will be the base of the column, overlap rod tie, with reinforced shoe thread, with annealed wire, steel rod, with thread, stroke axis, steel column, with a diameter of, caliber to calculate., squared shields, of steel, over the center., double hex nut, steel plate, rectangular side by side, that will be the base of the column, steel column, with a diameter of, caliber to calculate., welding, stainless steel plate, circular with an outside diameter, with a succión of inner diameter, welded screws plate no., with perforations to the shaft of the ring, screws to the axis of the center of the band, stainless steel plate, circular with an outside diameter, with a succión of inner diameter, with perforations to the shaft of the ring, steel plate, circular with an outside diameter, without welding to the tube of the column, stretched canvas, the shoe will be anchored, rods with threads tied, Shoe assembly rods, make a calculation of the shoe of the central column, stroke axis, anilleta, license plate

Raw text data extracted from CAD file:

\A1;10.000 \A1;5.000 \A1;7.500 \A1;2.500 \A1;10.000 \A1;2.500 \A1;R2.500 \A1;\U+22056.250 \A1;\U+22059.375 \A1;\U+220512.500 \A1;R10.000 \A1;80.000 \A1;100.000 \A1;5.000 \A1;15.000 \A1;25.000 \A1;10.000 \A1;45.000 \A1;75.000 \A1;50.000 \A1;60.000 \A1;80.000 \A1;80.000 \A1;57.938 \A1;36.398 \A1;80.000 \A1;105.985 \A1;19°44'53" \A1;109°44'53" \A1;70°15'7" \A1;70°15'7" \A1;30°0'0" \A1;30°0'0" \A1;135°0'0" \A1;45°0'0" 10.00000000000005 5 7.500000000000018 5 10.00000000000005 5 5 5 5 5 5 5 CANALETA DE ACERO PARA GUIA DE CABLE TENSOR CABLE TENSOR SOLDADA AL ESCUDETE PERRO DE SUJECION TENSOR GANCHO-ARGOLLA ESCUDETE DE ACERO DE MINIMO 3/4" DE ESPESOR SOLDADURA DE ESCUDETE A COLUMNA REMATE DE COLUMNA CON CORTE A 45° (la cara del corte orientada al centro de la columna mayor) SUAJE CIRCULAR CON DIAMETRO DE 2" PARA ENGANCHE DE TENSOR (dejar minima 1.5cms al corte del escudete) SUAJES DECORATIVOS del centro de la distancia de la parte superior a 2.5cms de la columna en la parte baja, se traza la linea y se divide en 4 partes iguales, que servira para los centros, el suaje superior mide 5" de diametro y el suaje inferior la mitad, el suaje central sale de las tangentes de los otros dos suajes. CABLE TENSOR COLUMNA DE ACERO CON UN DIAMETRO DE 12" CALIBRE POR CALCULAR. COLUMNA DE ACERO CON UN DIAMETRO DE 12" CALIBRE POR CALCULAR. EJE DE TRAZO DOBLE TUERCA HEXAGONAL ESCUDETES O CARTABONES DE ACERO 4@ 90° SOBRE EL CENTRO. PLACA DE ACERO DE 3/4" RECTANGULAR DE 45cms POR LADO QUE SERA LA BASE DE LA COLUMNA TUBO DE ACERO DE d 6" DE DIAMETRO EXTERIOR CALIBRE POR DEFINIR. DOBLE TUERCA HEXAGONAL. RONDANA METALICA. ESTRIBOS #3@15cm PLANTILLAS DE SUELO CEMENTO APISONADO O PEDACERA DE LADRILLO PARA NIVELACION. ZAPATA AISLADA DE CONCRETO ARMADO DE VARILLAS #6 @10cms EN AMBOS LADOS 5 -1.0 -1.0 -1.0 -1.0 -1.0 -1.0 -1.0 VARILLAS DEL # 6 ANCLADA HASTA LA ZAPATA. PLACA DE ACERO DE 3/4" RECTANGULAR DE 45cms POR LADO QUE SERA LA BASE DE LA COLUMNA TRASLAPE O AMARRE DE VARILLA CON ROSCA Y ARMADO DE ZAPATA CON ALAMBRE RECOCIDO VARILLA DE ACERO DE 3/4" CON ROSCA EJE DE TRAZO COLUMNA DE ACERO CON UN DIAMETRO DE 24" CALIBRE POR CALCULAR. ESCUDETES O CARTABONES DE ACERO 4@ 45° SOBRE EL CENTRO. DOBLE TUERCA HEXAGONAL PLACA DE ACERO DE 3/4" RECTANGULAR DE 80cms POR LADO QUE SERA LA BASE DE LA COLUMNA 60.00000000000014 5 5 5 5 5 5 COLUMNA DE ACERO CON UN DIAMETRO DE 24" CALIBRE POR CALCULAR. SOLDADURA 5 5 5 5 ANILLETA DE PLACA DE ACERO DE 3/4" CIRCULAR CON UN DIAMETRO DE 80cms EXTERIOR Y CON UN SUAJE DE 60cms DE DIAMETRO INTERIOR TORNILLOS DE 3/4" SOLDADOS A PLACA NO. 1 CON PERFORACIONES DE 3/4" AL EJE DEL ANILLO 5 5 12 TORNILLOS AL EJE DEL CENTRO DE LA ANILLETA ANILLETA DE PLACA DE ACERO DE 3/4" CIRCULAR CON UN DIAMETRO DE 80cms EXTERIOR Y CON UN SUAJE DE 60cms DE DIAMETRO INTERIOR CON PERFORACIONES DE 3/4" AL EJE DEL ANILLO PLACA DE ACERO DE 3/4" CIRCULAR CON UN DIAMETRO DE 80cms EXTERIOR SIN SUAJE, SOLDADA AL TUBO DE LA COLUMNA LONA TENSADA LONA TENSADA LA ZAPATA LLEVARA ANCLADAS LAS VARILLAS CON ROSCA Y AMARRADAS A LAS VARILLAS DEL ARMADO DE LA ZAPATA HACER CALCULO DE LA ZAPATA DE LA COLUMNA CENTRAL 5 5 EJE DE TRAZO EJE DE TRAZO ANILLETA PLACA 1

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete, Steel, Other
Measurement Units
Footprint Area
Building Features
Tags	autocad, base, construction, DETAIL, DWG, FOUNDATION, foundations, fundament, shoe, steel
