Skimmer in pool – Detail of dry channel

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

return water, water level, new floor of hammered cement, skimmer, reinforced concrete channel walls, electromal reinforced concrete channel base, dry channel detail, amateur pool, scale, water lamp, electric duct, tile, mosaic, skirting board

Raw text data extracted from CAD file:

\A1;0.70 \A1;0.60 \A1;0.05 \A1;0.10 \A1;0.75 \A1;0.05 \A1;0.40 \A1;0.05 \A1;1.20 5 5 5 RETORNO DE AGUA NIVEL DE AGUA PISO NUEVO DE CEMENTO MARTELINADO SKIMMER 5 5 PAREDES DE CANAL CONCRETO ARMADO 5 5 5 5 BASE DE CANAL DE CONCRETO ARMADO + ELECTROMALLA DETALLE DE CANAL SECO PISCINA MANGOS, AMATIQUE ESCALA : 1 : 12.5 LAMPARA ACUATICA DUCTO ELECTRICO AZULEJO MOSAICO RODAPIE
