This detail has all the markings to bring a court structure and descriptions of each

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

concrete template made of cm thick work, zapata concrete run armed with vs in both directions, cement foundation with cement block cm. seated with mortar filled concrete, firm of concrete sw of armada with electro welded mesh according to project., chain of cm. of section of reinforced concrete with rods stirrups each cm. finish, ceramic tile floor of interceramic brand cm, supply placement of anodized aluminum windows, ceramic tile floor of interceramic brand cm, wall of hollow block of cement of cm of thickness seated with mortar finished common, Concrete slab of cm of esp. punctured with double slab reinforced with vra ribs. in both directions, supply placement of anodized aluminum windows, wall of hollow block of cement of cm of thickness seated with mortar finished common, supply placement of anodized aluminum windows, wall of hollow block of cement of cm of thickness seated with mortar finished common, ceramic tile floor of interceramic brand cm, Concrete slab of cm of esp. punctured with double slab reinforced with vra ribs. in both directions, concrete roof slab of cm of esp. punctured with double slab reinforced with vra ribs. in both directions, elaboration of block block pretile with mortar prop, supply waterproofing termotek similar double action years afibratada, manufacture of linear gutter to avoid the trasminacion of humidity in the int, structural detail, esc:

Raw text data extracted from CAD file:

PLANTILLA DE CONCRETO HECHO EN OBRA FC=100Kg/Cm2, DE 5 Cm DE ESPESOR ZAPATA CORRIDA DE CONCRETO FC=200 KG/CM2 ARMADA CON VS DE 3/8 EN AMBOS SENTIDOS MÚRETE DE ENRASE EN CIMENTACION CON BLOCK DE CONCRETO 15X20X40 Cm. ASENTADO CON MORTERO CEMENTO-ARENA 1:5 RELLENO DE CONCRETO FC=100 Kg/CM2. FIRME DE CONCRETO F´C=150Kg/CM2 SW 10CM. DE ESPESOR, ARMADA CON MALLA ELECTRO SOLDADA 66/10-10, SEGÚN PROYECTO. CADENA DE DESPLANTE DE 15X20 CM. DE SECCION DE CONCRETO F´C=150 K/CM2 ARMADOCON 4 VARILLAS #3 ( 3/8" ) Y ESTRIBOS #2 ( 1/4" ) A CADA 20 CM. ACABADO COMÚN, PISO DE LOSETA CERAMICA DE 0.30X0.30 CM DE LA MARCA INTERCERAMIC SUMINISTRO Y COLOCACION DE VENTANAS V-4 DE 0.80X0.40CM DE ALUMINIO ANONIZADO DE 6MM PISO DE LOSETA CERAMICA DE 0.30X0.30 CM DE LA MARCA INTERCERAMIC MURO DE BLOCK HUECO DE CEMENTO DE 15X20X40 DE 15 CM DE ESPESOR ASENTADO CON MORTERO CEMENTO-ARENA 1:3 ACABADO COMUN LOSA DE CONCRETO Fc=200Kg/CM2 DE 15 CM DE ESP. AGUJERADA CON DOBLE LOSA Y ARMADO CON NERVADURAS DE C/2 VRA. #3 EN AMBOS SENTIDOS Y MALLA 66/10-10 SUMINISTRO Y COLOCACION DE VENTANAS V-4 DE 0.80X0.40CM DE ALUMINIO ANONIZADO DE 6MM MURO DE BLOCK HUECO DE CEMENTO DE 15X20X40 DE 15 CM DE ESPESOR ASENTADO CON MORTERO CEMENTO-ARENA 1:3 ACABADO COMUN SUMINISTRO Y COLOCACION DE VENTANAS V-4 DE 0.80X0.40CM DE ALUMINIO ANONIZADO DE 6MM MURO DE BLOCK HUECO DE CEMENTO DE 15X20X40 DE 15 CM DE ESPESOR ASENTADO CON MORTERO CEMENTO-ARENA 1:3 ACABADO COMUN PISO DE LOSETA CERAMICA DE 0.30X0.30 CM DE LA MARCA INTERCERAMIC LOSA DE CONCRETO Fc=200Kg/CM2 DE 15 CM DE ESP. AGUJERADA CON DOBLE LOSA Y ARMADO CON NERVADURAS DE C/2 VRA. #3 EN AMBOS SENTIDOS Y MALLA 66/10-10 LOSA DE AZOTEA DE CONCRETO Fc=200Kg/CM2 DE 15 CM DE ESP. AGUJERADA CON DOBLE LOSA Y ARMADO CON NERVADURAS DE C/2 VRA. #3 EN AMBOS SENTIDOS Y MALLA 66/10-10 ELABORACION DE PRETIL DE BLOCK DE 0.15X0.20X0.40 ASENTADO CON MORTERO PROP 1:4 SUMINISTRO Y COLOCACION DE IMPERMEABILIZANTE TERMOTEK O SIMILAR DOBLE ACCION AFIBRATADA 5 AÑOS FABRICACION DE GOTERON LINEAL PARA EVITAR LA TRASMINACION DE HUMEDAD EN EL INT DETALLE ESTRUCTURAL ZC-1 ESC: 1:25
