Detail of parapet to household water intake which specifies each of its accessories and installation specifications for social housing.
Drawing labels, details, and other text information extracted from the CAD file (Translated from Galician):
Garrison, Bench, Concrete template, Concrete dice, Simple, Simple wall for, Home delivery, Boundary limit, Detail of home-based installation, In a single wall a meter, Detail view plant, Adapter, Double heel pvc, Insert key, Piping for home water supply, Test of the norm, With the methods specifications of, Potable type ii rd that it meets, Anti-fraud valve for deplorable user, Single jet flow meter, Check valve type, Roscable male connector for extrupak, Tuboplus elbow of, Coupling for meter, Socket material, Roscable tuboplus male plug, Tuboplus tubing of, Front detail, Detail profile, Later detail, Double wall for home socket, Meters, Captions:, Project date:, August of, Location:, Signature:, Detail plane, Type split houses, Project:, Ing Hector alejandro cure barnetche, Ced. Profession:, place:, Fractionation heroes of nacozari, Budget, Double wall, Oomapasc, Murete c.f.e., Location of walls in the houses, Double wall, Oomapasc, The simple wall must be manufactured based on hydraulic concrete, Reinforced with rod anchor rod, Steel, Cm from the base to tie with the pipe of the internal pipe necessary accessories must be base, Tubof tubing thermofusion of, Certified under the specifications of the Mexican norm issued by the, Secretary of commerce industrial development the general direction of the finish must be polished having a total weight of kg., The developer of housing will be considered installing the garden key in the stretch that exists between the wall the side alley of, Access must be made with tuboplus material with the specifications indicated in the point, Piping for home delivery from the location of the drinking water line on the street to the front of the murete should be a pipe, Multilayer that meets the specifications of the test methods of the standard in measures of, Murete must have an antifraude valve for a depleted user of, It has the functions of closing partial closure, Valve from the valve body should be made of brass base with high nickel-plated finished sand., Of chromed sphere thickness with finishing packing vastago of control brass packing of vastago ring, In addition, it should meet a minimum operating temperature of maximum of the maximum pressure which operates is of, Screw that, The flow meter must be a single jet, it will be a requirement that it meets the following specifications: length height, Diameter with operating temperature of max. Temperature Of accidental operation temperature in the environment, Climatic of a maximum permissible pressure so that it can be installed in the murete type., The wall must be installed at the border of the wall symmetrically between the border of a housing for corner houses, In the case of not being apples, you will install a wall for a meter., For the installation of the first, a poor mold of hydraulic concrete must be strained, Of measurements, To later install the connectors in the wall so much in the front because the wall will drown in a die, Hydraulic concrete base, Of measures cms. To provide clamping to the ground., In the exit pipe immediately afterwards a check valve of the valve must be installed, With to avoid him, Return of the water from the dwelling to the murete., The dimensions of the murete other details are given in centimeters., The home delivery jack must be installed in the same one having a minimum separation between them of cms., Avoiding as much as possible the contamination of drinking water., The entrance of the home socket will be at the lower right front of the wall, the exit will be at the lower back, Left of the murete, Specifications, Garrison, Bench, Street, Variable length, Local, Limit of, Paramento, Detail view on the bypass plant, Potable water line of, Local
