Template DWG Block for AutoCAD

Template DWG Block for AutoCAD

Template – Colord panel 6mm – Wooden partition 12cm

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

manuel alejandro muñoz rivers, municipal lands curanilahue, educational cultural center in curanilahue, student:, theme:, Location:, scale:, professor Guide:, Carlos Marquez, date:, May, scantillon esc, detail esc, detail, court cut, stair lift, plant staircase scenic, detail railing, n.p.t, Beam h.a cm thick, zincalum channel, pre-painted instapanel cover mm, osv plate mm, mineral wool paper faces mm, rough pine mooring beam, steel anchor plate mm, tubular profile mm, steel plate on both sides, steel anchor plate mm, parapet h.a cm thickness, slab h.a cm thick, osv plate mm, wood partition cm, downstream rainy, natural terrain, Gravel layer cm, pillar h.a cm, false sky mooring grid, slab h.a cm thick, Beam h.a cm thick, thermopanel glass mm, compacted terrain, Beam h.a cm thick, floor flat cm, stick mortar, Anti-slip floor tile cm, smock, pre-painted instapanel cover, metallic profile drawer, laminated wood beam, canal zincalum mm, pre-painted instapanel cover, wool min. paper faces mm, pine skeleton, costaneras pino brute

Raw text data extracted from CAD file:

MANUEL ALEJANDRO MUÑOZ RÍOS TERRENOS MUNICIPALES CURANILAHUE CENTRO CULTURAL Y EDUCACIONAL EN CURANILAHUE ALUMNO: TEMA: UBICACIÓN: 8 ESCALA: PROFESOR GUIA: CARLOS MARQUEZ 1 : 100 FECHA: 26 de Mayo del 2003 ESCANTILLON ESC 1:20 Detalle 1 Esc 1: 10 Detalle 2 Esc 1: 5 Detalle 1 Detalle 2 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 F F CORTE F-F ESC 1:25 ELEVACION ESCALERA ESC 1:25 PLANTA ESCALERA ESC 1:25 Detalle Baranda 1:10 + 0.175 + 0.350 + 0.525 + 0.700 + 0.875 + 1.050 + 1.225 + 1.575 + 1.400 + 1.750 + 1.925 + 2.100 + 2.275 + 2.450 + 2.625 + 2.800 + 2.975 + 3.150 + 3.325 + 3.500 N.P.T + 1.225 N.P.T + 2.450 N.P.T + 1.225 0.175 0.175 Viga H.A 25 cm de espesor Canal zincalum 5mm Cubierta Instapanel prepintada 6 mm Placa OSV 20 mm Lana mineral papel 2 caras 50 mm Viga de amarre Pino Bruto Pletina de anclaje acero 5 mm Perfil Tubular o 10 mm Pletina acero 4mm por ambos lados Pletina de anclaje acero 5 mm Pletina de anclaje acero 5 mm Antepecho H.A 12 cm espesor Losa H.A 15 cm de espesor Placa OSV 20 mm Tabique madera 12 cm Bajada Aguas Lluvias terreno natural Capa de gravilla 10 cm Pilar H.A 25x70 cm Rejilla de amarre cielo falso Losa H.A 15 cm de espesor Viga H.A 25 cm de espesor Viga H.A 25 cm de espesor Viga H.A 25 cm de espesor Viga H.A 25 cm de espesor Viga H.A 25 cm de espesor Viga H.A 25 cm de espesor Viga H.A 25 cm de espesor Viga H.A 25 cm de espesor Viga H.A 25 cm de espesor Vidrio termopanel 8 mm Terreno compactado Viga H.A 25 cm de espesor Afinado de Piso 2 cm Mortero de Pega Baldosa antideslizantes 20x40 cm Guardapolvo Cubierta Instapanel prepintada 6mm Perfil metálico cajón 4mm Viga madera laminada 25x55cm Canal Zincalum 5 mm Cubierta Instapanel prepintada 6mm Lana min. papel 2 caras 50 mm Tijeral pino bruto 8x2 " Costaneras pino bruto 2x2 "

Language	Spanish
Drawing Type	Block
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Glass, Steel, Wood
