Transverse Section (Surveying) 2D DWG Section for AutoCAD

Mirror a cross-sectional 2D

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

right of way, road, road, shoulder, gutter, cut slope, slope of the gutter, main axis, embankment slope, folder, subbase, zero, base, crown

Raw text data extracted from CAD file:

\A1;72.2136 \A1;58.2397 \A1;20.3677 \A1;11.6973 \A1;12.5782 \A1;32.7120 Derecho de Vía 5 5 Explanacíon 5 Calzada Espaldon 5 Cuneta Talud de Corte 5 Inclinación de la cuneta eje principal Terraplen Talud Carpeta Sub-Base Cero Base 5 Corona
