This comprehensive floor plan depicts a two-story residential house with ground and first floor layouts, complemented by a location plan. The 25′-0″ wide house features three bedrooms, with two on the first floor and one on the ground floor. The ground floor contains a living room, kitchen, dining room, and garage accommodating one vehicle. A central staircase connects both floors, with clearly marked ‘UP’ and ‘DOWN’ indicators. The kitchen (9′-0″ x 8′-0″) adjoins the dining room (10′-0″ x 12′-0″), creating an efficient food preparation and dining zone. The location plan shows the property (Plot No 157) situated along a 30′ wide road, with neighboring plots (155, 159, and 160) clearly identified. Special attention has been given to circulation paths; door placements optimize flow between rooms while maintaining privacy for bedroom areas. The inclusion of both interior fixtures and boundary walls provides a complete spatial understanding for construction purposes.
Two-Story Residential Floor Plan with Garage and Location Plan
