Veneer-Finished Commercial Door Assembly with Hardware Details

This shop drawing details a commercial wood veneer door assembly with comprehensive elevation, section, and hardware mounting details. The assembly features a full-height door (approximately 7′-0″ to 8′-0″ tall) with natural wood veneer finish and architectural hardware. Elevations show both door faces with visible wood grain pattern, while sectional views detail the frame assembly, intumescent seals, and threshold conditions. Hardware includes hinges, latching mechanism, and door closers integrated into the assembly. The drawing includes architectural details for stone flooring transitions and includes specific door hardware designations (GF-41, GF-38, etc.) that reference project specifications. The assembly is designed with fire-rated components as evidenced by the intumescent seals and detailed edge conditions. Dimensions are provided in imperial units, with key measurements including a 3.2″ frame depth and 1.2″ door thickness.
