132mm Laser Cut Mounting Plate with Dimensioned Hole Spacing

2D CAD technical drawing of a 132mm mounting plate with five circular cutouts and dimensioned hole spacing.

Mechanical layout for a flat mounting bracket with five circular cutouts. Total lwngth is 132mm with hole spacing marked at 87.50 and 120.00mm.

FREE

File Details

File Type
DWG
Type
Detail
Language
English
Materials
Steel, Aluminum
Units
Metric
Area
1 – 9 m² (10.8 – 96.9 ft²)
Uploaded by
Blueprint Hub
Category
Mechanical, Electrical & Plumbing (MEP)
Published
May 27, 2026

Download faster, ad-free, with more daily files from $7/mo

Tags

132mm 2D detail bracket Cnc Corte Laser DWG hole pattern industrial hardware laser cutting mechanical part metal fabrication mounting plate
