This comprehensive architectural drawing set for a 5-bedroom duplex residence includes floor plans, elevations, sections, and detailed fixtures specifications. This design features a ground floor with main lounge (36 sq.m), dining area, kitchen (11 sq.m), study/gym (35 sq.m), guest bathroom, and maid’s quarters. The first floor contains 5 bedrooms including a master bedroom (22 sq.m), family lounge (25 sq.m), and multiple bathrooms. Construction details specify concrete foundation footings, 230mm hollow block walls, and reinforced concrete roof parapet. The finishing schedule indicates 600x600mm ceramic glazed flooring in living areas, 450x450mm non-slip vitrified tiles in wet areas, and ceramic wall tiling to 2100mm height in bathrooms. The roofing system employs 0.55mm colored long-span aluminum sheets on 50x75mm hardwood purlins at 900mm centers. Door specifications include hardwood-framed solid core mahogany flush doors with brass butt hinges and specialized security doors at main entrances.
5-Bedroom Duplex architectural Plans with Detailed Finishing Schedule
