A five-compartment steel locker cabinet designed for commercial or institutional use. The unit measures 2000×900×540mm with 1.2mm steel construction. Key Components: – Main, in essence, structure consists of side panels (1827×476×0.5mm), back panel (1825×878×0.4mm), and reinforcement brackets – Five individual compartments with separate doors featuring standardized hardware – Top box dimensions: 900×419×475mm with partition panels – Middle sections: 900×187mm and 900×486mm with support frames – Bottom section: 900×274mm with dual-door configuration – Internal support frames (250×60×0.4mm) provide structural rigidity – Door panel assemblies include reinforcement edging (829×100×0.4mm) The design incorporates strategic reinforcements at critical load-bearing points and optimized material thickness (0.4-0.5mm) to balance structural integrity with material efficiency. Door hardware includes standardized handles compatible with padlock security systems.
5-Box Steel Locker Cabinet Technical Assembly Drawing – 900mm Width
