Floor plans for a school extension project. Includes 3 general classrooms on RDC plus 2 specialized science labs (PC & SVT) and a prep room on the upper level. I’ve included the RC structural grid, masonry wall layouts, and joint de dilatation at 1:100 scale. Plans d’extension d’école avec salles d’enseignement général et laboratoires scientifiques.
5-Classroom School Extension with Science Labs and Prep Room
