Art School 3D DWG Model for AutoCAD

Art School 3D DWG Model for AutoCAD

School of Arts 3d – Facades

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

facades, contains:, location:, scale:, indicated, cadastral key:, milton guaman, student :, project:, esc. visual, location, preliminary project-school of arts, teacher :, arq. jorge gallegos, street tarqui, street ten of August, street first constituent, street eugenio mirror, street first constituent, street five of June, inter-American university of ecuador, unidec, faculty of architecture, goes up, ladies baths, duct of ventilation

Raw text data extracted from CAD file:

FACHADAS CONTIENE : UBICACION : FECHA: FEBRERO / 2012 ESCALA : INDICADAS CLAVE CATASTRAL: 01 05 MILTON GUAMAN ESTUDIANTE: PROYECTO : Esc. VISUAL UBICACION Calle 5 de Junio entre ao de Agosto y Primera Constituyente ANTEPROYECTO-ESCUELA DE ARTES Calle 5 de junio entre 10 de agosto y primera constituyente, esquina Club Ferroviario DOCENTE: ARQ. JORGE GALLEGOS 0 8 0 1 0 3 0 0 1 0 0 0 CALLE TARQUI CALLE DIEZ DE AGOSTO CALLE 10 DE AGOSTO CALLE PRIMERA CONSTITUYENTE CALLE 5 DE JUNIO CALLE EUGENIO ESPEJO CALLE TARQUI Mz. 64 Mz. 101 CALLE PRIMERA CONSTITUYENTE CALLE CINCO DE JUNIO Mz. 63 Mz. 65 Mz. 66 Mz. 76 Mz. 77 Mz. 78 Mz. 102 UNIVERSIDAD INTERAMERICANA DEL ECUADOR UNIDEC FACULTAD DE ARQUITECTURA FACHADA-CALLE 5 DE JUNIO ESCALA________ 1:1OO FACHADA-CALLE 10 DE AGOSTO ESCALA________ 1:1OO Sube Baños damas N +0.18m Ducto de ventilacion Sube Sube

Language	Spanish
Drawing Type	Model
Category	Schools
Additional Screenshots
File Type	dwg
Materials	Other
Measurement Units	Metric
Footprint Area
Building Features
Tags	art, arts, autocad, College, DWG, facades, library, model, school, university
