Barn – Metal Structure DWG Block for AutoCAD

Barn – Metal Structure DWG Block for AutoCAD

ATTIC TO RECEIVE GOODSES SEMI LIGHT.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

notes: plant structure roof, v b v b, revisions, m.s.m., client, date, description, for review and comments of the client, signature :, name :, frame a. del solar m., engineer, profession :, rut :, ind., rev., content:, plant and elevation, plane n, drawing scale date, profiles used :, -. perimeter beam:, view according to, -. central beam:, view according to b, metal structure -, lower cord:, uprights:, diagonal:

Raw text data extracted from CAD file:

\A1;6000 \A1;2970 \A1;6000 A 00 \A1;6000 \A1;6000 \A1;1500 \A1;1500 \A1;1500 \A1;1500 \A1;280 \A1;6280 \A1;500 \A1;2970 \A1;6000 \A1;500 \A1;1000 \A1;1000 \A1;1000 \A1;1000 \A1;1000 \A1;1000 \A1;150 \A1;150 \A1;150 \A1;100 \A1;150 \A1;150 \A1;100 \A1;100 \A1;50 \A1;50 \A1;500 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 \A1;DOBLE PLACA \A1; \A1;ESTRUCTURAL \A1;e=19 mm. \A1;PILAR H.A. \A1;EXISTENTE 5 5 5 5 5 5 \A1;VIGA RETICULADA \A1;VIGA RETICULADA \A1;VIGA RETICULADA 5 5 5 5 5 5 5 5 5 5 5 \A1; \A1; 3.- TODAS LAS MEDIDAS DEBERAN SER REVISADAS POR TERRENO 1.- DIMENSIONES EN MILIMETROS S.I.C. 2.- ELEVACIONES EN METROS NOTAS: ESCALA 1:50 PLANTA ESTRUCTURA TECHUMBRE 2 1 B A A - MAR.12 V B V B REVISIONES N- M.S.M. CLIENTE FECHA DESCRIPCION PARA REVISION Y COMENTARIOS DEL CLIENTE A FIRMA: NOMBRE: MARCO A. DEL SOLAR M. INGENIERO PROFESION: RUT: MAR. 2012 IND. M.S.M. REV. A CONTENIDO : PLANTA Y ELEVACION PLANO N 1 DIBUJO ESCALA FECHA PROYECTO ALTILLO - BODEGA 65 PERFILES EMPLEADOS: -. VIGA PERIMETRAL : -. PILARES : 150x150x5 -. CADENETEADO : C 75x40x3 (ESTOS ELEMENTOS, DEBEN IR SOLDADO EN SU TOTALIDAD) -. PLACA BASE : PLANCHAS e= 10 ESCALA 1:50 VISTA SEGUN A 2 1 100x100x4 100x100x4 -. VIGA CENTRAL : 200x150x5 ESCALA 1:50 VISTA SEGUN B A B B - ESTRUCTURA METALICA - -. VIGA RETICULADA ; CORDON INFERIOR : MONTANTES : DIAGONALES : 50x50x4 50x50x4 -. DIAGONAL PATA CENTRAL : 100x100x4

Language	Spanish
Drawing Type	Block
Category	Utilitarian Buildings
