Basement floor plan at 1/50 scale showing structural demolition requirements for the Hidiv Kasrı Villa project. It includes marked areas for breaking retaining walls, stairs, and specific concrete sections. A detailed 1/10 section is included for an existing column, highlighting reinforcement points. General notes specify that dimensions must be verified on-site and that existing steel reinforcements must be protected during the breaking process. The plan also mandates the use of electric compressors for the demolition work. – Main Basement Floor Plan: 1/50 scale – Column Breaking Detail: 1/10 scale – Symbols and abbreviations legend included – Material list for concrete, steel, and mesh.
Basement Floor Structural Demolition Plan and Column Detail Section
