This comprehensive drawing set presents a Brackish Water Reverse Osmosis (BWRO) system with detailed piping and instrumentation diagrams (P&ID) plus assembly views. The system features a treatment capacity of 63-79 m³/hr with key components including cartridge filters, high-pressure pumps (22kW, 380V/50Hz/3Ph/2900rpm), feed pumps (11kW, 380V/50Hz/3Ph/1450rpm), and static mixers. The piping system incorporates multiple materials including PVC, stainless steel 304/316L, and galvanized components with connection points for chemical dosing (antiscalant, biocide, SMBS, and post-chlorination). Instrumentation includes pressure indicators (PI), flow indicators (FI), pH sensors, ORP sensors, and TDS monitoring. The skid is constructed of UNP 100x50x5 and UNP 50x38x5 stainless steel profiles, with detailed views showing front, top, left, and right perspectives. The drawing includes control interfaces, valve schedules, and connection details for integration with CIP systems and raw/product water lines.
BWRO Water Treatment System P&ID and Assembly Drawings
