Camera Bt A-2 DWG Block for AutoCAD

Camera Bt A-2 DWG Block for AutoCAD

Camera BT A -2 – Plant – view – Enclosed measures

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

chest type, plant, cast iron fence, vibrated cm., concrete block, PVC tube mm., concrete block, vibrated cm., section, minimum, tube mm., tile pavement, nerves, unelco, b. t.

Raw text data extracted from CAD file:

\A1;Minimo 0.60 \A1;0.67 \A1;0.60 \A1;0.55 \A1;0.06 \A1;0.72 \A1;0.06 \A1;0.13 \A1;0.60 \A1;0.32 \A1;0.10 \A1;0.85 \A1;0.67 ARQUETA TIPO A-2 PLANTA B A CERCO HIERRO FUNDIDO VIBRADO 50x25x9 cm. BLOQUE DE HORMIGON TUBO PVC d125 mm. TUBO PVC d125 mm. BLOQUE DE HORMIGON VIBRADO 50x25x12 cm. SECCION A-B Minimo 0.60 5 TUBO d125 mm. TUBO d125 mm. PAVIMENTO DE LOSETA 4 NERVIOS 50 20 0.60 5 5 5 5 5 5 Unelco B. T. 5 5 5 5

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features
