electrical diagrams & force diagrams for a vacuum center control panel. incl. specific busbar dimensions (210mm, 225mm, 223mm), intelligent controller layout, plus mechanical details for the extraction device lever. drawn in metric for industrial automation projects and switchgear assemblies.
Circuit Breaker & Control Panel Detail DWG CAD Set
