Coffret De SÉCurité Oxygene – Vide DWG Block for AutoCAD

Coffret De SÉCurité Oxygene – Vide DWG Block for AutoCAD

Casket of separations and isolation of the special gaseous fluids in hospitable (hospital) and medical circles

Drawing labels, details, and other text information extracted from the CAD file (Translated from French):

safety cabinet, vacuum, oxygen – vacuum, valve of upstream isolation regulator, will allow the installation of an emergency regulator., valve of isolation downstream regulator, nota: the set of pressure taking upstream and downstream of the regulator , manometer or vacuum gauge, upstream manometer, pressure switch or vacuum switch, handle, anti-return, legend regulator empty, pressure tap downstream, upstream pressure tap, legend oxygen regulator, pressure gauge downstream

Raw text data extracted from CAD file:

175 Coffret de sécurité Vide 1 3 2 7 6 3 Oxygène - Vide 1 5 Vanne d'isolement amont détendeur 3 permettra la mise en place d'un détendeur de secours. Détendeur régulateur (Primaire - Secondaire) Vanne d'isolement aval détendeur NOTA : Le jeu de prise de pression amont et aval du détendeur Manomètre ou vacuomètre 1 Vacuomètre 0/1000 mb 5 6 Manomètre amont Pressostat ou vacuostat Prise 3/8 double clapet 4 Poignée Anti-retour 6 7 5 2 3 4 7 4 LEGENDE Régulateur VIDE Prise de pression aval Prise de pression amont 7 4 5 6 LEGENDE Régulateur OXYGENE 2 Manomètre aval Manomètre amont 1 2

Language	French
Drawing Type	Block
Category	Hospital & Health Centres
Additional Screenshots
File Type	dwg
Materials	Other
Measurement Units	Metric
Footprint Area
Building Features
Tags	air, autocad, block, circles, cooling, de, DWG, electrical installation, gas, health, Hospital, isolation, medical, special
