This comprehensive elevation drawing set details various commercial elevator door configurations with precise dimensional specifications. The drawing presents multiple elevator entrance designs with door panels ranging from 800mm to 1100mm in width, and standard heights of approximately 2100mm. Each assembly includes both the door panels (highlighted in yellow) and surrounding frames with dimensional callouts for installation clearances. The drawings feature both sectional views (top portions) and connection details (bottom portions) showing how the door assemblies integrate with surrounding wall structures. Distinctive elements include guide rails, door operators, and jamb details. The consistent dimensional format allows for standardized implementation across different elevator models while maintaining code-compliant clearances. Note how the frame designs accommodate various mounting conditions—particularly at header connections where structural support requirements are critical for proper door operation.
Commercial Elevator Door Assemblies elevation Drawing Set
