Concentric Cable Tripolar Bt DWG Block for AutoCAD

Cable of electric energy in low tension

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Zonal, Approved:, Department:, engineering department, district:, drawing:, design:, province:, Piura, flat:, Primary distribution network, Wireline diagram, scale:, date:, aug., Piura, Electronoroeste s.a., Electronoroeste s.a, sheet:, section, Insulation cover, Polyvinyl chloride, Copper annealed, Concentric outer conductor, Of polyvinyl pvc type, Inner coating of chloride, Red insulation, basic characteristics, material, Two copper conductors insulated with, Pvc type polyvinyl chloride red white color., Polyvinyl chloride extruded inner cover pvc, Color that brings together the two drivers., Black color, application, Is used for connections in the aerial network, Concentric outer conductor of copper annealed., Pvc polyvinyl chloride outer insulation cover, Chlor black., Copper core conductor annealed, White isolation

Raw text data extracted from CAD file:

ZONAL PIURA APROBÓ: DEPARTAMENTO: DEPARTAMENTO DE INGENIERIA DISTRITO: DIBUJÓ: DISEÑÓ: PROVINCIA: PIURA PLANO: RED DE DISTRIBUCION PRIMARIA DIAGRAMA UNIFILAR – CABLE 12A ESCALA: FECHA: S/E AGO. 98 PIURA 1/1 ELECTRONOROESTE S.A. ELECTRONOROESTE S.A LAMINA: SECCIÓN (mm2) 6 10 CUBIERTA AISLANTE DE CLORURO DE POLIVINILO ( PVC ) DE COBRE RECOCIDO CONDUCTOR EXTERIOR CONCÉNTRICO DE POLIVINILO ( PVC TIPO B ) CUBIERTA INTERNA DE CLORURO AISLAMIENTO ( ROJO ) CARACTERISTICAS BÁSICAS MATERIAL : Dos conductores centrales de cobre recocido, aislado con cloruro de polivinilo ( PVC tipo B ) color blanco y rojo. Cubierta interna extruída de cloruro de polivinilo ( PVC ) color negro, que reune a los dos conductores. color negro. APLICACIÓN Se emplea para acometidas en la red aérea ( B.T.) Conductor exterior concéntrico de cobre recocido. Cubierta aislante exterior de cloruro de polivinilo ( PVC ) clor negro. CONDUCTOR CENTRAL DE COBRE RECOCIDO AISLAMIENTO ( BLANCO )
